Hey all, anyone see this post yesterday about charging the R1T Max Pack from 1% to 100% off a 350kW charger?
How does this compare with a Large Pack charge curve?

Looks like 1%-80% (328mi) took 48 min. 20%-80% (246mi) took 38min.



Here's my attempt to crudely summarize her max pack charging experience:

SOC% (State of Charge)Charge RateCumulative kWh chargedTime Elapsed (hr:min)
1%198kW0:00
16%204kW25.6 kWh
20%196kW31.6 kWh0:10
30%154kW47.7 kWh0:15
33%165kW
34%145kW
40%137kW62.5 kWh0:21
40%183kW62.9 kWh0:21
49%157kW
55%144kW83 kWh0:28
65%135kW98.2 kWh0:35
67%109kW101.2 kWh0:36
70%110kW105.1 kWh0:38
73%90kW
76%83kW113 kWh0:43
77%63kW114.9 kWh0:44
80%63kW118.6 kWh0:48
85%56kW126.8 kWh0:56
100%137.4 kWh1:50
Sponsored


Last edited:

vandy1981

Well-Known Member
Joined
Jul 25, 2023
Threads
17
Messages
621
Reaction score
1,166
Location
USA
Vehicles
2023 R1S PDM MP, 2019 Jaguar I-Pace HSE
You're missing some time points at higher SOC--see my chart here:

edit: added my chart.

SOC (%)Speed (kW)Time (min)Energy (kWh)
4198??
16204?25.6
?1961031.6
301541547.7
401372162.5
551442883
651353598.2
6710939101.2
7011039105.1
768443113
776344114.9
806348118.6
855656126.8
885060130.1
924067136
953273136.9
997.2101137.3
1000113137.4

Per Rivian session summary page:
135 kWh battery pack
1.2 kWh Cabin and battery temps
1.2 kWh Accessories
137.4 kWh Total

Per EA session summary page:
147.568 kWh total

Last edited:

HaveBlue

Well-Known Member
Joined
Nov 22, 2022
Threads
21
Messages
1,429
Reaction score
1,061
Location
91107
Vehicles
R1S DMP Max, Lifted GX470, APR Audi A7, BMW 325Ci
Clubs

Similar curve from the looks but technically it's charge a little faster since it's a 149kw pack


COdogman

Well-Known Member
First Name
Brian
Joined
Jan 21, 2022
Threads
30
Messages
8,042
Reaction score
21,962
Location
Colorado
Vehicles
2023 R1T
Occupation
Dog Wrangler
Clubs

That’s like a bathroom break, burrito break, bathroom break, coffee break, bathroom break…

OP
OP
KCFGFE

KCFGFE

Active Member
Joined
Oct 24, 2023
Threads
1
Messages
40
Reaction score
24
Location
San Jose
Vehicles
R1S (Configured)
Similar curve from the looks but technically it's charge a little faster since it's a 149kw pack
Yeah, it seems the Large pack has about the same 20%-80% charge time of ~37min.
Ever since I saw Out of Spec's claim that the max pack wouldn't charge faster but at the same rate I really wanted to find out if that was true. "The charging speed is going to be identical between the two... The amount of range you're adding during a charging session is identical."

But like you mentioned, it's a larger pack with more usable kWh so with the same/similar curve you're going to be charging faster with more miles/min right?


Sponsored

mikehmb

Well-Known Member
First Name
Mike
Joined
Jan 12, 2022
Threads
95
Messages
1,431
Reaction score
2,938
Location
SF Bay Area
Vehicles
My name is Mike, and I have a (car) problem
137kWh is the Max Pack size?

What am I missing here. This chart doesn’t make sense.


VSG

Well-Known Member
Joined
Oct 3, 2022
Threads
3
Messages
1,820
Reaction score
3,371
Location
WA
Vehicles
R1T LE/RB/OC/20
Seems a little slower than expected at the peak. My experience is that my Large Pack will charge at >200kW between ~10% and ~40%.


GhostAndSkater

Well-Known Member
Joined
Feb 15, 2023
Threads
0
Messages
48
Reaction score
46
Location
Earth
Vehicles
A bycicle
Seems a little slower than expected at the peak. My experience is that my Large Pack will charge at >200kW between ~10% and ~40%.
It was expected since the way the achieve it is more energy dense cells instead of more cells

In most cases, energy density and charging time are opposites when compared in cells that the fundamental are close to each other

OP
OP
KCFGFE

KCFGFE

Active Member
Joined
Oct 24, 2023
Threads
1
Messages
40
Reaction score
24
Location
San Jose
Vehicles
R1S (Configured)
137kWh is the Max Pack size?

What am I missing here. This chart doesn’t make sense.
I think 142kWh was the Max pack usable capacity. Since the owner started charging at approximately 1%, some of the variance can be explained there.

This chart is mainly showing the charging time and charge rate for the new max pack since I haven't been able to find much info about it. I'm just going by what the owner posted on Twitter so it's missing some data points like elapsed time or total kWh charged.


mikehmb

Well-Known Member
First Name
Mike
Joined
Jan 12, 2022
Threads
95
Messages
1,431
Reaction score
2,938
Location
SF Bay Area
Vehicles
My name is Mike, and I have a (car) problem
I think 142kWh was the Max pack usable capacity. Since the owner started charging at approximately 1%, some of the variance can be explained there.

This chart is mainly showing the charging time and charge rate for the new max pack since I haven't been able to find much info about it. I'm just going by what the owner posted on Twitter so it's missing some data points like elapsed time or total kWh charged.
Oh yeah I get it - I trust you transcribed it correctly, but something about the base data doesn’t work.

135kWh for Large pack = 137+ for a full charge (other vampire drain during charging)

I think the Max is 149kWh, so call it maybe 152 for a full charge.

I don’t have a Twitter account so can’t see the source of my confusion, apologies.


Sponsored

COdogman

Well-Known Member
First Name
Brian
Joined
Jan 21, 2022
Threads
30
Messages
8,042
Reaction score
21,962
Location
Colorado
Vehicles
2023 R1T
Occupation
Dog Wrangler
Clubs

Oh yeah I get it - I trust you transcribed it correctly, but something about the base data doesn’t work.

135kWh for Large pack = 137+ for a full charge (other vampire drain during charging)

I think the Max is 149kWh, so call it maybe 152 for a full charge.

I don’t have a Twitter account so can’t see the source of my confusion, apologies.
Use Long dog’s Twitter account!


HaveBlue

Well-Known Member
Joined
Nov 22, 2022
Threads
21
Messages
1,429
Reaction score
1,061
Location
91107
Vehicles
R1S DMP Max, Lifted GX470, APR Audi A7, BMW 325Ci
Clubs

There's a whole thread but you have to log in to see the rest. The pics show power delivered and percentage full so simple math says 149kw usable battery

OP
OP
KCFGFE

KCFGFE

Active Member
Joined
Oct 24, 2023
Threads
1
Messages
40
Reaction score
24
Location
San Jose
Vehicles
R1S (Configured)
Oh yeah I get it - I trust you transcribed it correctly, but something about the base data doesn’t work.

135kWh for Large pack = 137+ for a full charge (other vampire drain during charging)

I think the Max is 149kWh, so call it maybe 152 for a full charge.

I don’t have a Twitter account so can’t see the source of my confusion, apologies.
Oh I see. I didn't realize a full charge would actually go over the usable capacity due to drain from other systems.


mikehmb

Well-Known Member
First Name
Mike
Joined
Jan 12, 2022
Threads
95
Messages
1,431
Reaction score
2,938
Location
SF Bay Area
Vehicles
My name is Mike, and I have a (car) problem

COdogman

Well-Known Member
First Name
Brian
Joined
Jan 21, 2022
Threads
30
Messages
8,042
Reaction score
21,962
Location
Colorado
Vehicles
2023 R1T
Occupation
Dog Wrangler
Clubs

Long Dog does not approve of Twitter use in his house.
One more reason to love him. Twitter = “happy hat”
