Warmer months are approaching and I for one could not be more excited! But that also means car ovens are back, and Rivians are no exception to that, in fact we often hear our Rivian clients complaining of how hot their Rivian seems to get in the summer.

Many can be mislead with the term 'factory tinted' windows, but this is typically referring to privacy glass also know as dyed glass. The glass in this case has pigments and dye added into the glass directly at manufacturing. While the glass does give off the appearance of being tinted, it does not give you the benefits. The glass can still let in harmful UV rays that are responsible for skin tanning, skin aging and wrinkles, which can also contribute to skin cancer. Adding a layer of nano ceramic film can reject up to 99% of UV rays which gives your skin a layer of protection, as well as reduces the sun damage on the vehicles upholstery and dash. A nano ceramic tint also provides Infrared (IR) rejection, IR is responsible for the majority of the heat you feel on you when you're seating in your vehicle. Nano ceramic films offer a range of IR protection depending on which film you go with.

Another cool thing about tint, is that it can double as protection from shattered glass. The adhesive and protective polyester layers help hold the shattered glass in place, reducing the chances of the glass flying into the vehicle and harming you or a passenger in the event of an accident. Which also can cause window breakers to think twice before smashing your window.

A common question we get is "does tint go on the outside or the inside of a vehicle?" It does go on the inside of the car, if a piece of film needs a shrink, which is common for windshields and sunroofs, then the tint will get shrunk on the outside of the glass, but it will still get installed on the inside.

If you currently have tint on your windows or are planning on getting tint in the future, do not use glass cleaner that has ammonia in it. Ammonia can break down and remove the adhesive that holds the tint on glass, thus casing the tint to peel or discolor. We like to use Sprayway and XPEL Glass Cleaner, using a waffle or micro fiber towel is recommended.

Another common questions we get is what kind of tint and what % of tint are other Rivian owners getting. While like a lot of things, it comes down to personal preference, there are some common trends we see. Choosing which level of tint usually comes down to how much the heat bothers the client, if their skin is sensitive to the sun, if they are driving around children and price.
While the options and brands vary at shops in the area, we use XPEL Tint and we offer 3 different levels of film to choose from.
Color Stable - more commonly called CS - Carbon tint - rejects 99% of UV and has some glare reduction.
This is typically your cheapest tint and most people will get it for privacy or aesthetic. People who get this tint usually get it in a 20% or 30% on their front two windows, so that the windows match the back better. 20% means that 20% of the light is still coming through the windows. If their back windows do not have a factory dyed glass, then they typically get it on the back side windows and rear window as well.
XR Black - Nano Ceramic tint - Single layer tint - rejects 99% of UV and 78% of IR - has more glare reduction then CS.
This is one of the more common tint option for our Rivian clients, is provides a good amount of heat rejection. One of our more common requests is 70% on the windshield, 20% or 30% on the front two side windows, 70% on the back side windows, rear windows and sunroof.
XR Plus - Nano Ceramic tint - muti layer tint - rejects 99% of UV and 96% of IR - has the most glare reduction.
This will be the most expensive tint and best for those who have kids, have sensitive skin and wants the most protection.

Nano ceramic benefits that carbon tint does not provide:
- Superior heat rejection.
- Enhanced clarity.
- Durability and Fade Resistance.
- Signal Friendly.
- Skin Cancer Foundation Recommendation.
- Extended battery range, as the vehicle is spending less energy to cool the vehicle.

While we do see a lot of Rivian clients opt for the popular package above, we get all kind of requests. Some will want 5% all the way around and others will want 70% all the way around. Others will tint only the front two windows so they match closer to rear windows. Most tints will offer some kind of warranty on their film, again this can very from shop to shop and brand to brand. XPEL offers a lifetime tint warranty and is the Rivian chosen brand proven by XPEL-Rivian Referral Program. Our shop specifically is a part of this program and we also offer a lifetime warranty on the installation!

If you have questions about the program, about tint in general or want some quotes, do not hesitate to reach out and we would be more then happy to help!

Call or text: 206-453-8900
Email: [email protected]
Visit our website: SeattleClearBra.com

Rivian R1T R1S Common Tinting Practices Seattle-clearbra-redmond-tint-nano-ceramic-xr-black-xpel-6


Rivian R1T R1S Common Tinting Practices Seattle-clearbra-redmond-tint-nano-ceramic-xr-black-xpel-24


Rivian R1T R1S Common Tinting Practices Seattle-clearbra-redmond-tint-nano-ceramic-xr-black-xpel-41


Rivian R1T R1S Common Tinting Practices Seattle-clearbra-redmond-tint-nano-ceramic-xr-black-xpel-33


Rivian R1T R1S Common Tinting Practices Seattle-clearbra-redmond-tint-nano-ceramic-xr-black-xpel-86


Rivian R1T R1S Common Tinting Practices Seattle-clearbra-redmond-tint-nano-ceramic-xr-black-xpel-105


Rivian R1T R1S Common Tinting Practices Seattle-clearbra-redmond-tint-nano-ceramic-xr-black-xpel-113


Rivian R1T R1S Common Tinting Practices Seattle-clearbra-redmond-tint-nano-ceramic-xr-black-xpel-170


Rivian R1T R1S Common Tinting Practices Seattle-clearbra-redmond-tint-nano-ceramic-xr-black-xpel-137
Sponsored



Krs71

Well-Known Member
First Name
Krish
Joined
Nov 27, 2021
Threads
1
Messages
75
Reaction score
23
Location
Las Vegas
Vehicles
R1S
Occupation
IT
Great info, thank you....I do have a question, I ceramic tint on my R1S, 2 front windows matching rear, windsheild and roof 70%. I live in Vegas so it gets hot, the 70% roof didn't seem to help much, since I put in shades, I was talking to my tint guy and was exploring layering 20% on top of the 70 for the roof to darken and idea is to remove the shades out of the car. Will that make the glass too hot and cause cracking? Will I get the additional heat rejection ?


Oldcarguy

Member
First Name
Larry
Joined
Feb 8, 2025
Threads
0
Messages
23
Reaction score
12
Location
SETX
Vehicles
R1T Quad, 911, 1928 Ford P/U
Occupation
Retired
Great information, Thank you.
I too am considering tinting the roof.
I also have concerns about cracking glass.


onthebrake

Well-Known Member
First Name
David
Joined
Feb 10, 2021
Threads
4
Messages
112
Reaction score
89
Location
Placentia, CA
Vehicles
2022 Rivian R1T LE - 3/31/2022 Took Delivery
Occupation
Project Manager
FYI I tinted my roof on my LE R1T, almost 3 years ago, with limo tint. The darkest possible. I’ve never had a problem. I live in SoCal.


Krs71

Well-Known Member
First Name
Krish
Joined
Nov 27, 2021
Threads
1
Messages
75
Reaction score
23
Location
Las Vegas
Vehicles
R1S
Occupation
IT
FYI I tinted my roof on my LE R1T, almost 3 years ago, with limo tint. The darkest possible. I’ve never had a problem. I live in SoCal.
how well does it keep out the heat with it being that dark?


Sponsored

OP
OP
SeattleClearBra

SeattleClearBra

Well-Known Member
Site Sponsor
Joined
Jan 24, 2023
Threads
14
Messages
127
Reaction score
125
Location
Redmond Washington
Vehicles
BMW
Occupation
Paint Protection Film Window Tint Vinyl Ceramic Installer
Clubs

Great info, thank you....I do have a question, I ceramic tint on my R1S, 2 front windows matching rear, windsheild and roof 70%. I live in Vegas so it gets hot, the 70% roof didn't seem to help much, since I put in shades, I was talking to my tint guy and was exploring layering 20% on top of the 70 for the roof to darken and idea is to remove the shades out of the car. Will that make the glass too hot and cause cracking? Will I get the additional heat rejection ?
What kind of ceramic tint do you have on your windows? Some ceramic tints block a lower amount of IR then other ceramic tints. For instance XPELs XR Black tint only rejects 78% IR but their XR plus rejects 96% of the IR.


Krs71

Well-Known Member
First Name
Krish
Joined
Nov 27, 2021
Threads
1
Messages
75
Reaction score
23
Location
Las Vegas
Vehicles
R1S
Occupation
IT
What kind of ceramic tint do you have on your windows? Some ceramic tints block a lower amount of IR then other ceramic tints. For instance XPELs XR Black tint only rejects 78% IR but their XR plus rejects 96% of the IR.
XPEL plus

OP
OP
SeattleClearBra

SeattleClearBra

Well-Known Member
Site Sponsor
Joined
Jan 24, 2023
Threads
14
Messages
127
Reaction score
125
Location
Redmond Washington
Vehicles
BMW
Occupation
Paint Protection Film Window Tint Vinyl Ceramic Installer
Clubs

Great information, Thank you.
I too am considering tinting the roof.
I also have concerns about cracking glass.
The likely hood of your sunroof cracking due to tint is very small. There has been some Rivian roofs that have cracked for what seems like no apparent reason that did not even have tint. Odds are there was a flaw at manufacturing which makes the glass weaker and more susceptible to breaking with outside elements like weather, pressure change, jolts from speed bumps or pot holes.

OP
OP
SeattleClearBra

SeattleClearBra

Well-Known Member
Site Sponsor
Joined
Jan 24, 2023
Threads
14
Messages
127
Reaction score
125
Location
Redmond Washington
Vehicles
BMW
Occupation
Paint Protection Film Window Tint Vinyl Ceramic Installer
Clubs

XPEL plus
Are all your windows tinted or just some of them?
You could add another layer of tint but some issues that might come up is that the adhesive is meant to adhere to the window so it might be more prone to peeling up and having some defects. It also might fade and cancel out the warranty. I would double check with your shop that if those issues were to come up, would they just take it off and replace it at no cost. Some people have defiantly done it and had zero issues!


Krs71

Well-Known Member
First Name
Krish
Joined
Nov 27, 2021
Threads
1
Messages
75
Reaction score
23
Location
Las Vegas
Vehicles
R1S
Occupation
IT
Are all your windows tinted or just some of them?
You could add another layer of tint but some issues that might come up is that the adhesive is meant to adhere to the window so it might be more prone to peeling up and having some defects. It also might fade and cancel out the warranty. I would double check with your shop that if those issues were to come up, would they just take it off and replace it at no cost. Some people have defiantly done it and had zero issues!
Front 2 windows, windsheild and roof are tinted currently, was wondering to layer the roof on top of the 70% that's there with another 20%.


Sponsored

OP
OP
SeattleClearBra

SeattleClearBra

Well-Known Member
Site Sponsor
Joined
Jan 24, 2023
Threads
14
Messages
127
Reaction score
125
Location
Redmond Washington
Vehicles
BMW
Occupation
Paint Protection Film Window Tint Vinyl Ceramic Installer
Clubs

Front 2 windows, windsheild and roof are tinted currently, was wondering to layer the roof on top of the 70% that's there with another 20%.
I would suggest getting the rest of the vehicle tinted first with the XR plus and seeing how that does. Because heat is still coming through the side windows, when it is all uniformed, it gives you the best heat rejection!


onthebrake

Well-Known Member
First Name
David
Joined
Feb 10, 2021
Threads
4
Messages
112
Reaction score
89
Location
Placentia, CA
Vehicles
2022 Rivian R1T LE - 3/31/2022 Took Delivery
Occupation
Project Manager
how well does it keep out the heat with it being that dark?
I used the best ceramic IR tint that money can buy, so it rejects the heat VERY well.
